Module 4 : Deflection of Structures
Lecture 3 : Principle of Virtual Work
  Example 4.17 Using the diagram multiplication method, determine the horizontal displacement and rotaion of point C of the rigid-jointed plane frame shown in Figure 4.23. Both the members of the frame have same EI value.

  Solution: The free-body and bending moment diagram (B.M.D.) of the frame due to applied loading are shown in Figures 4.23(b) and (c), respectively.







Horizontal deflection of C : Apply a horizontal force at C as shown in Figure 4.23(d) and plot the bending moment diagram as shown in Figure 4.23(e). The horizontal deflection at C is given by multiplying the diagrams of Figure 4.22 (c) and (e) as follows






1
