Module 6 : PHYSICS OF SEMICONDUCTOR DEVICES
Lecture 35 : Photoconductivity



  Consider an n-type semiconductor. If the recombination life time for the minority carriers is $ \tau_p$, the rate of change of carrier concentration is given by

$\displaystyle \frac{d}{dt}(\Delta p) = \frac{\eta\alpha I}{h\nu}-\frac{\Delta p}{\tau_p}$
  Under steady state condition $ d\delta p/dt=0$, which gives

$\displaystyle \delta p = \frac{\eta\alpha I_p\tau_p}{h\nu}= \Delta n$
  This excess hole density leads to an additional conductivity

$\displaystyle \Delta\sigma = q\delta n\mu_e + q\Delta p \mu_h$
