Module 5 : Force Method - Introduction and applications
Lecture 3 : Analysis of Statically Indeterminate Structures by Energy Method

Example 5.17 Determine the force in various members of the pin-jointed frame shown in Figure 5.20(a). Length and AE is constant for all members.





Solution: The static indeterminacy of the pin-jointed frame is =12+3–7×2 = 1. Let the force in the member BG be R as shown in Figure 5.20(b). According to the Castigliano's theorem







The computation of is made in Table 5.6.


Table 5.6


Member
Length, L ( m )
P
Final force (kN)
AB
2
-120 +R
1
2 R- 240
-40
AG
2
120 -R
-1
2 R- 240
40
AF
2
-60 +R
1
2 R- 120
20
BC
2
-120 +R
1
2 R- 240
-40
BG
2
-R
-1
2 R
-80
CD
2
-120 +R
1
2 R- 240
-40
CG
2
120 -R
-1
2 R- 240
40
DE
2
-60 +R
-1
2 R- 120
20
DG
2
60 -R
-1
2 R- 120
-20
EF
2
-60 +R
1
2 R- 120
20
EG
2
60 -R
-1
2 R- 120
-20
FG
2
60 -R
-1
2 R- 120
-20




  or


                                                  R = 80 kN

  The final force in various members of the frame is shown in Table 5.6.
