Module 5 : Force Method - Introduction and applications
Lecture 3 : Analysis of Statically Indeterminate Structures by Energy Method

Example 5.20 Analyze the portal frame shown in Figure 5.23 by strain energy method.





Solution: Static indeterminacy of the frame = 2. Horizontal and vertical reactions at A are taken as redundant.

For the span AB ( x measured from A ),
















Since



or                     6 V + 4 H = 3 wL

 (i)


and



or                     32 V + 12 H = 15 wL

 (ii)


Solving Eqs (i) and (ii) for H and V ,
