III.1.3 Laplace transform of a few basic functions
The Fig. III.1 shows a few basic functions which are frequently used in process control applications
|
|
|
|
Fig. III.1: Few basic functions which are frequently used in process control applications |
|
(a) Step function
(b) Ramp function
(c) Pulse function
(d) Impulse function Step function : See Fig. III.1(a) for the schematic of a step function
